MEIAL Horizontal Anodizing Production Line Equipment For Aluminum Profile

MEIAL Horizontal Anodizing Production line equipment for Aluminum Profile

一.Production Description

1.Anodizing production line incorporate intelligent maintenance systems, such as predictive and condition-based monitoring, to anticipate equipment failures and optimize maintenance schedules.

2.The anodizing production line collects and analyzes a large amount of data from its processes to generate detailed reports, performance dashboards, and data-driven decisions.

3.The anodizing production line works closely with customers and design teams during the product development phase to ensure optimal part design and material selection for effective and efficient anodizing.

二. Design Condition

三.Process Tank

四. Treatment Process:

1. Degreasing
   (1) 6jig(rack)/ tank x 1 tank=6jig(rack)
   (2) treatment time: 2-5min
2.  Alkaline Etching
   (1) 6jig(rack) / tank x 2 tank=12jig(rack)
   (2) treatment time: 3-15min
3.  Neutralization
   (1) 6jig(rack) / tank x 1 tank=6jig(rack)
   (2) treatment time: 1-5min
4.  Anodizing
   (1) 3 jig(rack)/tank x 5tanks = 15jig(rack)
   (2) Current density: 130A/m²
   (3) Process time: 30min
   (4) Unprocess time: 10min
   (5) Total time 30+10=40min

          (6) Average anodizing layer : 0.36*1.3*30*0.77 =10.81um

5.  Colour 1

                     1) Clour process: Mix Salts

                     2) Quantity:2 jig(rack)/tank x 1tanks = 2jig(rack)

                     3) Current density: 70A

                     4) Process time: 2-8min

      6. Sealing
           1) Sealing menthod:  Sealing at Medium or Normal Temperature
           2) Quantity:6jig(rack)/tank x 1 tank
           3) Process time 10-15min

五. Design Parameter and Setting

       1. Anodizing treatment area:
              1) Each anodizing process tank need 40min ,where total jig(rack)/year:​

                   ( 2rack x 5 tank x 60min/h) ÷40min x600 hour =9000jig(rack)

2) Design 50m²^/jig(rack) . Where every tank is 100m²
3) Area treatment/year : 9000jig(rack)x 50m² /jig =450000m²

2.  Anodizing treatment weight:
        Monthly output : 450000m²÷350m²/T*0.9=1157.1T≧1000T

3. Power consumption:
        1) Anodising Tank:100m²/tank* 130A/ m²÷0.9=14444A/tank

           Power Rectifier : 15000A =5unit
        2) Clouring tank: 100㎡/tank×70A/m²÷0.9 = 7777A/tank

   Colour Rectifier : 8000A =2 unit

六. Process Chat
